CH™ Concealed-Head Self-Clinching Studs and Standoffs

CH™ Concealed-Head Self-Clinching Studs and Standoffs

PDF page 19 · PEM Fastener Catalogue

PEM® concealed-head self-clinching studs and standoffs install permanently and promote smooth designs.

Key Information: Brand Entity: PEM® (registered trademark Visual Elements: Blue block lettering, large blue inverted triangle Background: Horizontal brushed metal textureProduct: PEM® concealed-head self-clinching stud (CH™ Features: Threaded shank with a knurled/serrated head. Function: Designed for permanent installation into thin sheets to provide a secure attachment point while maintaining a smooth exterior surface.Entity: CH™ Concealed-head self-clinching standoff. Features: Threaded cylindrical body with a hexagonal base for flush mounting in thin sheets. Material: Metal (likely stainless steel or aluminum. Application: Used as a fastener to create space between components in electronic or mechanical assemblies.Key Information: Entity: Technical schematic of a concealed-head self-clinching stud. Dimension L: Represents the overall length of the threaded portion. Dimension C: Indicates the diameter of the clinching head. Shank Specification: Shows a maximum unthreaded shank length of .062" / 1.6 mm below the head. Design Features: Illustrates a threaded fastener with a serrated clinching base designed for permanent, flush installation.
